Motherboards

Processor & Chipset

• Chipset Manufacturer:     Intel
• Chipset Model:     3210
• Total Processor Supported:     1
• Processor Technology:     Enhanced SpeedStep Technology
• Processor Socket:     Socket T LGA-775
• Processor Supported:     Xeon
• Processor Supported:     Core 2 Quad
• Processor Supported:     Core 2 Duo
• Front Side Bus:     1333 MHz
• Front Side Bus:     1066 MHz
• Front Side Bus:     800 MHz

Memory

• Number of Memory Slots:     4
• Maximum Memory:     8 GB
• Memory Standard:     DDR2-800/PC2-6400
• Memory Standard:     DDR2-667/PC2-5300
• Memory Technology:     DDR2 SDRAM

I/O Controller

• Controller Type:     Floppy Controller
• Controller Type:     Serial ATA/300

Video

• Onboard Video:     On-board Video Chipset
• Graphics Controller Manufacturer:     ATI
• Graphics Controller Model:     ES1000
• Graphics Controller Memory:     32 MB

Network & Communication

• Gigabit Ethernet:     Yes

I/O Expansions

• Number of Total Expansion Slots:     6
• Number of PCI Slots:     2
• Number of PCI-X Slots:     2
• Total Number of PCI Express Slots:     2
• Number of PCI Express x4 Slots:     1
• Number of PCI Express x8 Slots:     1

Interfaces/Ports

• Total Number of USB Ports:     2
• Number of USB 2.0 Ports:     2
• Serial Port:     Yes
• VGA:     Yes
• Network (RJ-45):     Yes

Onboard Interfaces

• Number of SATA Interfaces:     6
• Total Number of Onboard USB Ports:     2
• Onboard LEDs Header:     Yes

Physical Characteristics

• Form Factor:     ATX
• Width:     12.0"
• Depth:     9.6"

Miscellaneous

• Additional Information:
• ROHS Compliant
• Dual Channel memory supported Chipsets:
• Intel 3210
• ICH9R
• PXH
• Intel 82573V
• Intel 82573L

  BIOS Features:

• 16Mb Flash EEPROM with Phoenix BIOS
• Plug and Play (PnP)
• DMI 2.3 support
• PCI 2.2
• ACPI 1.0/2.0
• SMBIOS 2.3
• USB Keyboard support

  Hardware Monitoring:

• Monitors for CPU Cores ( +1.8V, +3.3V, +5, ±12V, +3.3V Standby, +5V Standby, VBAT, HT, Memory, Chipset)
• CPU Core 3-Phase-switching voltage regulator with auto-sense from 0.3750V-1.6000V
• Adjustable CPU clock frequency ratio
• Total of six 4-pin fan headers
• 6 x fans with tachometer monitoring
• Status monitor with firmware / software speed control
• Status monitor for on/off control
• Support 3-pin fans (without speed control)
• Low noise fan speed control
• Pulse Width Modulated (PWM) fan connector
• Monitoring for CPU and chassis environment
• CPU Thermal Trip support
• Thermal Monitor (TM2) Support
• PECI
• Onboard voltage monitors for CPU cores, Memory Voltage, +1.8V, +3.3V, +5V, +5V Standby, +12V, 12V, and VBAT CPU 4-phase-switching voltage regulator
• Status monitor for fan speed & System OH/Fan Fail LED/Control
• Pulse Width Modulation Fan Control & Low noise fan speed control
• Environmental temperature monitoring via BIOS
• Power-up mode control for recovery from AC power loss
• Supero Doctor III
• NMI
• System Resource alert via Supero Doctor III
• Slow blinking LED for suspend state indicator
• BIOS support for USB keyboard
• Main switch override mechanism

  Supported Operating Systems:

• MS Win 2000 Advanced Server + SP4
• MS Win XP Pro + SP2
• MS Win Vista Ultimate
• MS Win Vista Home Premium
• MS Win 2003 Server Enterprise Edition
• MS Win XP Pro x64
• MS Win 2003 Server x64
• Redhat Linux 4 (Update 5)
• Redhat Linux 5
• Open SuSE Linux 10.2
• SuSE Linux 10
• RedHat Linux 4 (Update 5) x64
• Redhat Linux 5 x64
• Fedora Core 7 x64
• Open SuSE Linux 10.2 x64
• Open SuSE Linux 10.2 x64
